Fexible Fiberglass Mesh for EIFS

Short Description:

Product Detail

Product Tags

Description Of Fiberglass Mesh

Flexible fiberglass  mesh is a woven fiberglass mesh which is an important part of a contentious stucco or EIFS assembly. Flexible Fiberglass mesh is embedded into the base coat layer to provide reinforcement and resistance to cracking and alkali. When applied with other necessary wall components to meet code, the exterior finish will have durable, alkali resistant structure that helps minimize cracking.

fiberglass mesh  2
fiberglass mesh 9
fiberglass mesh 12

alkaline-resistance

soft/standard/hard mesh

500mm-2400mm 30g/㎡-600g/㎡

Detals Of Fiberglass Mesh

fiberglass mesh 3

Product Name: Flexibel Fiberglass Mesh
Material & Process: C-glass or E-glass woven fabric, coated with acrylic acid copolymer liquid.

Application:
● EIFS and wall reinforcement
● Roof Waterproof

● Stone Reinforcement
● Sticky mesh for EPS or wall corner

Properties :

  • Polymer coated
  • Leno weave
  • Non-adhesive
  • Durable and impact resistant
  • Flame retardant
fiberglass mesh 11
fiberglass mesh 4

Specification Of Fiberglass Mesh

Item No. Density Count/25mm Finished Weight(g/m2) Tensile Strength *20 cm Woven Structure Content of Resin% (>)
warp weft warp weft
A2.5*2.5-110 2.5 2.5 110 1200 1000 Leno/leno 18
A2.5*2.5-125 2.5 2.5 125 1200 1400 Leno/leno 18
A5*5-75 5 5 75 800 800 Leno/leno 18
A5*5-125 5 5 125 1200 1300 Leno/leno 18
A5*5-145 5 5 145 1400 1500 Leno/leno 18
A5*5-160 4 4 160 1550 1650 Leno/leno 18
A5*5-160 5 5 160 1450 1600 Leno/leno 18

Packing and Delivery



fiberglass mesh 6
fiberglass mesh 7
fiberglass mesh 8
fiberglass mesh 5

Picture:
